8BitDo N30 2.4G Wireless Controller - Original NES

The 8BitDo N30 2.4G Wireless Controller provides cable-free control on an original Nintendo Entertainment System using the included dedicated wireless receiver.

Simply connect the receiver to an original NES-style controller port and press Start on the controller to establish its responsive 2.4GHz wireless connection. No Bluetooth adapter, external receiver purchase or permanent console modification is required.

Its slim shape and familiar control layout take their inspiration from the original NES gamepad. The controller combines a directional pad with A and B action buttons, Start and Select controls, dedicated TA and TB Turbo buttons and a HOME control for accessing the Analogue Nt Mini menu wirelessly.

Wireless compatibility includes original Nintendo Entertainment System consoles, the Nintendo Famicom HVC-101, Analogue Nt and Analogue Nt Mini. The original Famicom HVC-001 is not directly compatible because its controllers are hardwired and it does not provide the required standard controller port.

Because the controller and receiver operate as a matched 2.4G system, there is no Bluetooth pairing process or separate adapter to configure. This model does not contain Bluetooth and cannot connect through Bluetooth receivers or BlueRetro adapters.

Nintendo Switch and Windows 10 are additionally supported through a wired USB-C connection. These modern-system connections are wired rather than wireless, and the included original NES receiver is not used.

A built-in 180mAh rechargeable lithium-ion battery provides approximately 18–20 hours of play and requires around one to two hours for a full charge.

This listing is specifically for the Transparent Black N30 2.4G NT original-console model with USB-C. It should not be confused with the separate N30 controller and receiver set designed for the Nintendo NES Classic Edition.

Finished in Transparent Black, the controller is dispatched from UK stock with fast delivery, international tracked delivery to supported destinations and a 12-month Retrolize warranty.

Browse our complete range of wireless controllers for retro and modern systems.

Brand: 8BitDo
Product Name: N30 2.4G
Product Type: 2.4G Wireless NES Controller & Receiver
Model: N30 2.4G NT
Manufacturer Product Code: 81BC
Edition: Transparent Black USB-C Edition
Wireless Technology: Dedicated 2.4GHz Connection
Wireless Receiver: Included Dedicated N30 Receiver
Receiver Connection: Original NES-Style Controller Port
Receiver Power: Console Controller Port
Controllers Per Receiver: 1
Bluetooth: Not Supported
Console Modification Required: No
Wireless Compatibility: Original NES, Famicom HVC-101, Analogue Nt & Analogue Nt Mini
Wired USB Compatibility: Nintendo Switch & Windows 10
Control Layout: D-Pad, A, B, Start, Select, TA, TB & HOME
Turbo Controls: TA For Turbo A & TB For Turbo B
Analogue Nt Mini HOME Menu Access: Supported Wirelessly
Physical Analogue Sticks: Not Included
Controller Vibration: Not Supported
Motion Controls: Not Supported
Battery: Built-In 180mAh Rechargeable Lithium-Ion Battery
Battery Life: Approximately 18–20 Hours
Charging Time: Approximately 1–2 Hours
Charging & Wired Connection: USB-C
Firmware Updating: Supported With Official Model-Compatible Firmware
Dimensions: 123.8 × 53.5 × 19.7mm
Controller Weight: Approximately 72.5g
Colour: Transparent Black
SKU: 8BD-N30-TBLK

Wireless Console Compatibility

Original Nintendo Entertainment System NES-001 Consoles: Supported With The Included Receiver
Original Nintendo Entertainment System NES-101 Consoles: Supported With The Included Receiver
Nintendo Famicom HVC-101 / AV Famicom Consoles: Supported With The Included Receiver
Analogue Nt Consoles: Supported With The Included Receiver
Analogue Nt Mini Consoles: Supported With The Included Receiver

Wired USB Compatibility

Nintendo Switch: Supported Through A Wired USB-C Connection
Windows 10 PCs: Supported Through A Wired USB-C Connection

Controller Functions

Directional Pad: Supported
A & B Action Buttons: Supported
Start & Select Controls: Supported
TA & TB Turbo Buttons: Supported
Analogue Nt Mini HOME Menu Access: Supported Wirelessly
Dedicated 2.4G Wireless Connection: Supported With The Included Receiver
Controllers Per Receiver: One
Two-Player Wireless Use: Requires Two Controllers & Two Dedicated Receivers

Compatibility Limitations

Nintendo NES Classic Edition: Not Supported By The Included Original-Console Receiver
Original Nintendo Famicom HVC-001 Consoles: Not Supported Directly
Bluetooth Connections: Not Supported
BlueRetro Bluetooth Adapters: Not Supported
Other 8BitDo Receivers & Adapters: Not Supported
Other Consoles & Devices With Similar Controller Ports: Compatibility Not Guaranteed
Physical Analogue Sticks: Not Included
Controller Vibration: Not Supported
Motion Controls: Not Supported

Connection Requirements

Controllers Per Receiver: One
Receivers Required For Multiplayer: One Matching Receiver For Each Controller
Wireless Receiver Connection: Original NES-Style Controller Port
Modern-System Connection: Wired USB-C
Console Modification: Not Required
External Receiver Power Supply: Not Required
Hot Plugging: Not Supported

Original-Console Version: This is the N30 2.4G NT model supplied with a receiver for original NES-style controller ports. It is not the separate N30 model designed for the Nintendo NES Classic Edition.

Dedicated Receiver Required: Wireless gameplay requires the matching 2.4G receiver included with the controller. Bluetooth receivers, BlueRetro adapters and other 8BitDo receivers are not supported.

NES Classic Edition Not Supported: The included receiver does not fit or operate with the Nintendo NES Classic Edition. That console requires the separate N30 model supplied with a compatible miniature-console receiver.

Original Famicom HVC-001 Not Supported Directly: The original Nintendo Famicom HVC-001 uses hardwired controllers and does not provide the standard controller port required by the included receiver. The later Famicom HVC-101, also known as the AV Famicom or New Famicom, is supported.

One Receiver Per Controller: Each wireless controller requires its own dedicated receiver and available controller port. Two-player wireless gaming requires two controllers and two receivers.

Wired USB Compatibility: Nintendo Switch and Windows 10 are supported through a wired USB-C connection. The included original NES receiver is not used with these systems.

Current USB-C Revision: This Transparent Black edition uses USB-C for charging and supported wired gameplay. Older N30 versions may use a different charging connection.

Analogue Nt Mini HOME Function: The controller includes a dedicated HOME control for accessing the Analogue Nt Mini menu wirelessly.

Feature Limitations: The controller does not include Bluetooth, physical analogue sticks, vibration or motion controls.

Hot Plugging: Always switch the console off before inserting, removing or changing the receiver.

Firmware Compatibility: Only install official firmware released specifically for the N30 2.4G NT controller and matching original-console receiver. Incorrect, incompatible, unofficial or interrupted firmware updates may render the controller or receiver inoperable.

Console Not Included: The controller, receiver and listed accessories are supplied. Any console or other equipment shown in the product images is for demonstration only.

First-Time Wireless Connection

1. Switch the original NES, Famicom HVC-101, Analogue Nt or Analogue Nt Mini off.
2. Connect the included 2.4G receiver to an available controller port.
3. Switch the console on. The receiver indicator should begin flashing.
4. Press Start on the N30 controller to switch it on and establish the wireless connection.
5. Wait for the receiver indicator to remain solid, confirming that the connection is successful.
6. Test the directional pad and buttons before starting a game.
7. Once connected, the controller and receiver should normally reconnect when the console and controller are switched on again.
8. Always switch the console off before removing or changing the receiver.

Using TA & TB Turbo Buttons

TA: Provides rapid Turbo A input.

TB: Provides rapid Turbo B input.

Use the standard A or B button for normal input and the corresponding TA or TB button when rapid repeated input is required.

Turbo is provided through the dedicated TA and TB controls. Button behaviour during wired USB operation can vary according to the connected system and software.

Receiver Indicator

Flashing Indicator: The receiver is waiting for or attempting to establish a wireless connection.

Solid Indicator: The controller and receiver are connected successfully.

Wired Nintendo Switch Use

1. Connect the N30 directly to a USB port on the Nintendo Switch dock using the supplied USB-C cable.
2. If the controller is not detected, open System Settings > Controllers And Sensors and enable Pro Controller Wired Communication.
3. Allow the Nintendo Switch to recognise the controller.
4. Test the controls before starting a game.
5. The included original NES receiver is not used for wired Nintendo Switch operation.

Wired Windows 10 Use

1. Connect the N30 directly to the Windows 10 computer using the supplied USB-C cable.
2. Allow Windows to detect the controller.
3. Configure the controls within the intended game, emulator or controller-compatible software where required.
4. The included original NES receiver is not used for wired Windows operation.

Firmware Updating

Firmware and supporting files are available through official 8BitDo Support.

Select the N30 2.4G NT entry and only install firmware explicitly released for the original-console controller and matching receiver. Maintain a stable USB connection throughout the update and do not disconnect the controller until the process has finished.

1 × 8BitDo N30 2.4G Wireless Controller In Transparent Black
1 × Dedicated 2.4G Receiver For Original NES-Style Controller Ports
1 × USB-C Cable
1 × Instruction Manual
1 × Retail Box

This 8BitDo N30 2.4G Wireless Controller is covered by a 12-month Retrolize warranty against manufacturing defects and hardware faults arising during normal use from the date of delivery.

The warranty does not cover accidental damage, liquid damage, misuse, damaged charging or receiver connections, unauthorised modification, normal cosmetic wear or the expected reduction in rechargeable battery capacity through normal use and ageing.

Damage, loss of function or bricking caused by installing incorrect, incompatible or unofficial firmware, interrupting a firmware update or carrying out an update incorrectly is not covered by the warranty.

Compatibility differences involving unsupported consoles, third-party receivers, Bluetooth adapters, USB equipment or unlisted operating systems are not considered product faults.

Warranty claims remain subject to the full Retrolize warranty terms and are additional to the customer’s statutory rights.

Does This Controller Work With An Original NES?

Yes. Original Nintendo Entertainment System consoles are supported using the included dedicated receiver.

Does It Work With The Famicom HVC-101?

Yes. The Famicom HVC-101, also known as the AV Famicom or New Famicom, provides the compatible controller ports required by the receiver.

Does It Work With The Original Famicom HVC-001?

Not directly. The original HVC-001 has hardwired controllers and does not provide the standard controller port required by the included receiver.

Does It Work With Analogue Nt & Nt Mini Consoles?

Yes. Analogue Nt and Analogue Nt Mini consoles are supported using the included receiver.

What Does The HOME Control Do?

The dedicated HOME control allows the Analogue Nt Mini menu to be accessed wirelessly.

How Is This Different From The Other N30 2.4G Controller?

This is the N30 2.4G NT model supplied with a receiver for original NES-style controller ports. The separate N30 2.4G model for the Nintendo NES Classic Edition uses a different receiver and is not interchangeable.

Does The N30 2.4G Use Bluetooth?

No. This model uses a dedicated 2.4GHz wireless connection with its included matching receiver. It cannot connect to Bluetooth adapters, receivers or devices.

Can It Be Used With Nintendo Switch Or Windows 10?

Yes. Nintendo Switch and Windows 10 are supported through a wired USB-C connection. Wireless operation on these systems is not supported by the included original NES receiver.

Does This Version Use USB-C?

Yes. This current Transparent Black edition uses USB-C for charging and supported wired gameplay.

What Do The TA & TB Buttons Do?

TA provides Turbo A input and TB provides Turbo B input, allowing rapid repeated input without repeatedly pressing the standard A or B button.

Can Two Wireless Controllers Be Used Together?

Yes. Each player requires one N30 controller, one matching receiver and one available console controller port.

Can It Connect To Another 8BitDo Receiver?

No. The controller is designed to work wirelessly with the dedicated 2.4G receiver supplied with it.

Does It Work With The Nintendo NES Classic Edition?

No. The included receiver is designed for original NES-style controller ports. The NES Classic Edition requires a separate N30 version with a different receiver.

How Long Does The Battery Last?

The built-in 180mAh rechargeable battery provides approximately 18–20 hours of play and requires around one to two hours for a full charge.
